Cisco Compatible DWDM-XFP-XXXX-80 | 10G DWDM XFP Transceiver LC SMF 80km (C-Band)
Buy Cisco compatible 10G DWDM XFP transceiver (C-Band ITU grid), LC duplex, up to 80km over SMF. Ideal for long-haul telecom and high-density DWDM networks.
Cisco Compatible DWDM-XFP-XXXX-80 10GBASE-DWDM XFP Optical Transceiver (LC Duplex, C-Band, 80km)
Product Overview
The Cisco compatible DWDM-XFP-XXXX-80 optical transceiver is a high-performance 10Gbps module designed for long-distance Dense Wavelength Division Multiplexing (DWDM) applications over single-mode fiber (SMF). Operating on the ITU-T DWDM C-Band grid, it enables high-density multi-channel transmission over a single fiber pair, maximizing bandwidth efficiency and network scalability.
With a transmission reach of up to 80 kilometers, this XFP module is ideal for telecom backbone networks, metro aggregation, and long-haul enterprise optical transport systems requiring extended reach and high-capacity wavelength multiplexing.
“XXXX” represents the DWDM channel (e.g., CH17–CH61) or corresponding ITU frequency (e.g., 191.7THz–196.1THz).
Available Channel Options (Example)
Model Variant | ITU Channel | Frequency (THz) | Approx. Wavelength (nm) |
|---|---|---|---|
DWDM-XFP-CH17-80 | CH17 | 191.7 | ~1563.86 |
DWDM-XFP-CH21-80 | CH21 | 192.1 | ~1560.61 |
DWDM-XFP-CH25-80 | CH25 | 192.5 | ~1557.36 |
DWDM-XFP-CH29-80 | CH29 | 192.9 | ~1554.13 |
DWDM-XFP-CH33-80 | CH33 | 193.3 | ~1550.92 |
DWDM-XFP-CH37-80 | CH37 | 193.7 | ~1547.72 |
DWDM-XFP-CH41-80 | CH41 | 194.1 | ~1544.53 |
DWDM-XFP-CH45-80 | CH45 | 194.5 | ~1541.35 |
DWDM-XFP-CH49-80 | CH49 | 194.9 | ~1538.19 |
DWDM-XFP-CH53-80 | CH53 | 195.3 | ~1535.04 |
DWDM-XFP-CH57-80 | CH57 | 195.7 | ~1531.90 |
DWDM-XFP-CH61-80 | CH61 | 196.1 | ~1528.77 |
Key Features
- Supports data rates up to 10Gbps
- DWDM technology for ultra high channel density
- Operates on ITU-T C-Band DWDM grid (100GHz spacing typical)
- Transmission distance up to 80km over SMF
- LC Duplex connector
- Compatible with DWDM MUX/DEMUX systems
- Compliant with XFP MSA and IEEE 802.3ae
- Hot-pluggable XFP form factor
- Built-in Digital Diagnostic Monitoring (DDM/DOM)
- High-power optical design for long-haul transmission
- 100% compatible with Cisco platforms (custom coding available)
- RoHS compliant and Class 1 laser safety certified
Technical Specifications
Parameter | Specification |
|---|---|
Form Factor | XFP |
Data Rate | 10Gbps |
Wavelength / Frequency | ITU-T DWDM C-Band (≈1528–1565nm) |
Channel Spacing | 100GHz (0.8nm typical) |
Fiber Type | Single-Mode Fiber (SMF) |
Max Distance | 80km |
Connector | LC Duplex |
Transmitter Type | Cooled EML Laser |
Receiver Type | APD Photodiode |
Output Power | +2 ~ +6 dBm |
Receiver Sensitivity | ≤ -23 dBm |
Extinction Ratio | > 4 dB |
Power Consumption | < 4.5W |
Operating Temperature | 0°C to 70°C (Commercial) |
Storage Temperature | -40°C to 85°C |
Protocols Supported | IEEE 802.3ae, XFP MSA |
Digital Diagnostics | Yes (DDM/DOM Supported) |
Applications
- Long-distance DWDM optical transmission systems
- Telecom backbone and core networks
- Metropolitan Area Networks (MAN)
- Enterprise optical transport over extended distances
- Data center interconnect (DCI)
- High-density wavelength multiplexing deployments
Compatibility
This module is fully compatible with Cisco switches and routers supporting XFP interfaces and can be custom-coded for Huawei, Juniper, and other major networking platforms. It integrates seamlessly with standard DWDM MUX/DEMUX systems.
Why Choose This DWDM-XFP-XXXX-80 Module?
- Enables high-density 10G channels over a single fiber pair
- Supports long-haul transmission up to 80km
- Optimized for scalable DWDM network expansion
- Fully tested for compatibility and reliability
- Ideal for legacy XFP-based telecom systems
- OEM/ODM support including labeling and coding customization
- Reliable supply for large-scale infrastructure projects
Ordering Information
Part Number | Description |
|---|---|
DWDM-XFP-XXXX-80-C | 10G DWDM XFP, LC, SMF, 80km (Specify channel) |
