Cisco Compatible CWDM-XFP-XXXX-80 | 10G CWDM XFP Transceiver LC SMF 80km
Buy Cisco compatible 10G CWDM XFP transceiver (1470–1610nm), LC duplex, up to 80km over SMF. Long-distance solution for metro and telecom CWDM networks.
Cisco Compatible CWDM-XFP-XXXX-80 10GBASE-CWDM XFP Optical Transceiver (LC Duplex, 1470–1610nm, 80km)
Product Overview
The Cisco compatible CWDM-XFP-XXXX-80 optical transceiver is a high-performance 10Gbps module designed for long-distance Coarse Wavelength Division Multiplexing (CWDM) applications over single-mode fiber (SMF). Supporting wavelengths from 1470nm to 1610nm, it enables multiple 10G channels over a single fiber pair, significantly improving bandwidth utilization and reducing fiber deployment costs.
With a transmission reach of up to 80 kilometers, this XFP module is ideal for telecom backbone networks, metro aggregation, and long-haul enterprise optical transport systems.
“XXXX” represents the CWDM wavelength option (e.g., 1470, 1490, 1510, 1530, 1550, 1570, 1590, 1610nm).
Available Wavelength Options
Model Variant | Wavelength |
|---|---|
CWDM-XFP-1470-80 | 1470nm |
CWDM-XFP-1490-80 | 1490nm |
CWDM-XFP-1510-80 | 1510nm |
CWDM-XFP-1530-80 | 1530nm |
CWDM-XFP-1550-80 | 1550nm |
CWDM-XFP-1570-80 | 1570nm |
CWDM-XFP-1590-80 | 1590nm |
CWDM-XFP-1610-80 | 1610nm |
Key Features
- Supports data rates up to 10Gbps
- CWDM technology for multi-channel transmission
- Wavelength range: 1470nm to 1610nm
- Transmission distance up to 80km over SMF
- LC Duplex connector
- Compliant with XFP MSA and IEEE 802.3ae
- Hot-pluggable XFP form factor
- Built-in Digital Diagnostic Monitoring (DDM/DOM)
- Compatible with standard CWDM MUX/DEMUX systems
- High-power optical design for long-haul transmission
- 100% compatible with Cisco platforms (custom coding available)
- RoHS compliant and Class 1 laser safety certified
Technical Specifications
Parameter | Specification |
|---|---|
Form Factor | XFP |
Data Rate | 10Gbps |
Wavelength | 1470–1610nm (CWDM grid) |
Channel Spacing | 20nm |
Fiber Type | Single-Mode Fiber (SMF) |
Max Distance | 80km |
Connector | LC Duplex |
Transmitter Type | DFB / EML Laser |
Receiver Type | APD Photodiode |
Output Power | +2 ~ +6 dBm |
Receiver Sensitivity | ≤ -23 dBm |
Extinction Ratio | > 4 dB |
Power Consumption | < 4.0W |
Operating Temperature | 0°C to 70°C (Commercial) |
Storage Temperature | -40°C to 85°C |
Protocols Supported | IEEE 802.3ae, XFP MSA |
Digital Diagnostics | Yes (DDM/DOM Supported) |
Applications
- Long-distance CWDM optical transmission systems
- Telecom backbone and core networks
- Metropolitan Area Networks (MAN)
- Enterprise optical transport over extended distances
- Data center interconnect (DCI)
- Multi-channel wavelength multiplexing deployments
Compatibility
This module is fully compatible with Cisco switches and routers supporting XFP interfaces and can be custom-coded for Huawei, Juniper, and other major networking platforms. It integrates seamlessly with standard CWDM MUX/DEMUX systems.
Why Choose This CWDM-XFP-XXXX-80 Module?
- Enables multiple 10G channels over a single fiber pair
- Supports long-haul transmission up to 80km
- Cost-effective solution for expanding network capacity
- Fully tested for compatibility and performance
- Ideal for legacy XFP-based telecom systems
- OEM/ODM support including labeling and coding customization
- Reliable supply for large-scale network deployments
Ordering Information
Part Number | Description |
|---|---|
CWDM-XFP-XXXX-80-C | 10G CWDM XFP, LC, SMF, 80km (Specify wavelength) |
